API 5L Steel Grade X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2
API 5L specification covers seamless and welded steel line pipe. It includes standard weight and extra strength tubing. It includes standard weight and extra-strong thread tube; and standard-weight-plain-end, regular-weight-plain-end, special plain, extra-strong plain, special plain, extra-hard plain pipe; as well as bell and spine and through-the-flow line (TFL) tubing.
Table of Content
隐藏
The purpose of this specification is to provide standards for pipe suitable for use in the transmission of gas, water, and oil in the oil and gas industry.
API 5L Carbon Steel Pipes Grade B, X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 Importers, Stockist, Supplier, Distributor and Exporter in India. Delivery quality API 5L Grade B, C, X42 X52 X56 X60 X65 and X70 on time. Fast delivery guaranteed for all sizes stainless steel API 5L GR.B PSL 1 Pipe, carbon steel API 5L GR.B PSL 2 Pipe, various API 5L GR.B PSL 1/2 Pipe other suppliers .
The specifications for API 5L follow the International Organization for Standardization ISO 3183, which is the standard for transportation in pipelines in equipment, equipment and external standards for petroleum, petrochemical, and oil industry. The standards committee recognized that there are two levels of Product Specification (PSL) requirements and therefore created PSL 1 and PSL 2. PSL 1 is a standard for pipelines that PSL 2 contains supplements, mechanical equipment, and test rules.
Product features:
Resistant to corrosion
Specification:
| Standards | API 5L |
|---|---|
| Grade | API 5L Gr A, B, X42, X46, X52, X56, X60, X65, X70, PSL 1/ 2, ETC |
| Size | Seamless = ½” NB – 24” NB ERW = 16” OD – 120” OD |
| Thickness | 6.35mm – 65mm |
| Length | Single Random & Double Random |
| End | Plain End, Beveled End, Threaded |
Material & Grade :
| Carbon Steel : Grade: WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70 |
Chemical Composition
| Chemical Composition % | ||||||||
| PSL1 | PSL2 | |||||||
| Grade | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) | C (Max.) | Mn(Max.) | P(Max.) | S(Max.) |
| A | 0.22 | 0.90 | 0.03 | 0.03 | 0.22 | 1.20 | 0.025 | 0.015 |
| B | 0.26 | 1.20 | 0.03 | 0.03 | 0.22 | 1.30 | 0.025 | 0.015 |
| X42 | 0.26 | 1.30 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X46 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X52 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X56 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.40 | 0.025 | 0.015 |
| X60 | 0.26 | 1.40 | 0.03 | 0.03 | 0.22 | 1.45 | 0.025 | 0.015 |
| X65 | 0.26 | 1.45 | 0.03 | 0.03 | 0.22 | 1.65 | 0.025 | 0.015 |
| X70 | 0.26 | 1.65 | 0.03 | 0.03 | 0.22 | 1.85 | 0.025 | 0.015 |
Mechanical Properties
| Mechanical Properties PSL 1 | |||||
| Grade | Yield Strength(Min.) | Tensile Strength(Min.) | Elongation | ||
| Ksi | MPa | Ksi | MPa | E=1944 A 0.2 /U 0.9 | |
| B | 35 | 241 | 60 | 414 | |
| X42 | 42 | 290 | 60 | 414 | |
| X46 | 46 | 317 | 63 | 434 | |
| X52 | 52 | 359 | 66 | 455 | |
| X56 | 56 | 386 | 60 | 414 | |
| X60 | 60 | 414 | 63 | 434 | |
| X65 | 65 | 448 | 66 | 455 | |
