Din BS EN stander flange introduction

We are recognized as a reliable manufacturer, supplier and exporter of DIN Flanges, DIN Raised Flanges, DIN Standard Flanges, Flat Face DIN Flanges, ASME B16.47 / ANSI B16.5 DIN Flanges, DIN Plate Flanges , Series A & B DIN Flanges, DIN Forged Flanges, MSS SP-44 DIN Flanges, DIN86029 PN10 DIN Flanges, Class 150, 300, 600, 900, 1500 DIN Flanges Dimensions.

Types of DIN Flanges
Size ½” (15 NB) to 48″ (1200NB)
Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 etc.
DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN26632, DIN2632, DIN2632, DIN2632, DIN2628
BS 4504, BS4504, BS1560, BS10
In the form of SORF, WNRF, BLRF, SWRF, LAP Joint, Threaded, Reduced, Show, etc.

Standard: ANSI B16.5, ANSI B16.47, ANSI B16.36, ANSI B16.48, BS 4504, EN1092, UNI 2277/2278, DIN, JIS, SABS1123, GOST-12820
Coating/surface treatment anti-rust painting, oil black, transparent yellow, zinc plated, cold and hot dip galvanized
Joint Type Ring Type Magnetic, Round Art Face, Raised Face, Flat Face, Large Male-Female, Male-Female, Large, Tongue & Groove, Small Tongue & Groove
Flanges Face Type Flat Face (FF), Raised Face (RF), Ring Joint (RJT)
Dimensions ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
Packed Without Smoked or Fumigated Plywood / Wooden Pallet or Case
Use/Application Oilfield, Outdoor, Water System, Shipbuilding, Natural Gas, Electricity, Pipeline etc.

Product, Standard, & Grade of DIN FLANGES
Stainless Steel DIN Flanges ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904
Duplex Steel DIN Flanges ASTM / ASME A / SA 182 F 44 F 45 F51 F 53 F 55 F 60 F 61
Super Duplex DIN Flanges ASTM / ASME A / SA 182 F 44 F 45 F51 F 53 F 55 F 60 F 61

IMENSIONS OF DIN FLANGES

AVAILABLE TYPES OF DIN FLANGES
